Fire Rated Linings For Sealing Metal Consumer Units
Rated 3.5/5 based on 11 customer reviews

Fire Rated Linings For Sealing Metal Consumer Units

Available: In Stock

    All metal consumer units are non-combustible, however majority of cables and conduits that connect to them are flammable, therefore necessitating the use of intumescent gaskets to seal them off in a fire.

    The intent of Regulation 421.1.201 is considered to be, as far as is reasonably practicable, to contain any fire within the enclosure or cabinet and to minimise the escape of flames, and this is as true of metal consumer units as it is of plastic ones.

    Envirograf® manufactures a range of intumescent linings, which in the event of a fire will seal up cable entries, containing the fire within the non-combustible box.

    Other sizes can be made to order.

    Intumescent Strip for metal consumer unit
    protecting the back of the box
    SCUB1         100mm x 60mm
    SCUB2         150mm x 60mm
    SCUB3         150mm x 100mm

    Intumescent Strip for metal consumer unit
    protecting the top, bottom and back of the box
    SCU/SET   Set of 3 Strips (Top: 50mm x 300mm coloured black- Bottom: 75mm                         x 300mm coloured black- Back: 75mm x 300mm coloured red)

    Hollow wall back entry sleeve

    SCUS1        105mm x 85mm x 40mm deep
    SCUS2        85mm x 40mm x 40mm deep
